5’ X 10’ CNC Routing System with Komo GE Fanuc Panel i CNC Controller w/Alpha HVI Digital Servo Motors, 16HP 24K RPM HSK-63A Newly Rebuilt Spindle, 12 Position Rotary Tool Changer, Vacuum Table with TRAVAINI TRO 400S-1A Dynaseal 25 HP Dyna-Seal Vacuum Pump and Torit 20 Cyclone Bag Type Dust Collector.


GENERAL SPECIFICATIONS
  • Capacities: 60” X 120”
  • Spindle Type: HSK 63
  • Spindle Horsepower: 16 HP Spindle Motor
  • Tool Changer Type: Carousel/Rotary
  • Positions: 12 Position
  • Feed/Rapid Traverse Rates:
  • X-Axis: 3,150 IPM
  • Y-Axis: 2,300 IPM
  • Z-Axis: 1,200 IPM
  • Toolsetter: Automated
  • Lubrication: Automatic Lubrication System (control activated)

Controller:

  • Make: Fanuc Controller
  • Setup Interface: Fanuc Hand Held Remote Pendant
  • Model: GE Fanuc Panel i CNC w/Alpha HVI
  • Drive: Digital Servo Motors
  • Diagnostics: Includes Remote Diagnostics
  • Interface Keyboard,Touch Screen and Touch Probe
  • Cooling: Air Conditioner for electrical panel
  • Production Management: Komo Production Manager Software

Vacuum Pump Specifications:
  • Make: Travaini
  • Type: TRS100-550
  • Model: TR0400S-1A
  • Stages: Single stage
  • Bearing Type: External sealed bearings
  • Cooling: Air Cooled
  • Capacity: 400ACFM @ 20 in. HgV
  • Max. vacuum: 27 in. HgV
  • Drive: Baldor
  • Horsepower: 25 HP Motor
  • Voltage: 480V, 3 Phase
  • RPM: 1760
  • Drive Type: Direct drive
  • Weight: 1,631 lbs

Dust Collector:

  • Make: Donaldson / Torit
  • Model: 20 Cyclone
  • Type: Dust Collector
  • Cleanout: Manual Clean/Dump After Filter (includes bag filter assy)
  • Horsepower: 5 HP
  • Inlet: 8" diameter inlet
  • CFM: 1,500 - 2,500 cfm
  • Dust Container: 30 Gallon Hopper
  • Voltage: 460

INCLUDES:   Komo GE Fanuc Panel i CNC Controller w/Alpha HVI Digital Servo Motors, 16HP 24KRPM HSK-63A Newly Rebuilt Spindle, 12 Position Rotary Tool Changer, Vacuum Table with TRAVAINI TRO 400S-1A Dynaseal 25 HP Dyna-Seal Vacuum Pump and Torit 20 Cyclone Bag Type Dust Collector. Replacement Value 185K as New


***We strongly encourage personal inspection of all pieces of used equipment***
***All Price, Location and Specifications Subject to Change without Notice***

Sold
